Product Details
Place of Origin: Shenzhen, China
Brand Name: COMLED
Certification: FCC,ETL,DLC,CE,SAA,AS2293.3,Rosh
Model Number: ZL-VSBLP44-5FT-CN-V2
Payment & Shipping Terms
Minimum Order Quantity: 1000pcs
Price: US$33.6-US$40.32 /piece
Delivery Time: 7-30 days(sample around 3-7 days)
Payment Terms: T/T
Supply Ability: 10000pcs per month
Rated Power: |
44w |
Luminous Efficacy: |
120-150lm/W |
CCT: |
Changeable |
Input Power Supply(v): |
AC 220 |
Warranty: |
5 Years |
Working Temperature: |
-20 - 40(℃) |
Housing Material: |
Stainless Steel |
Install: |
Linkable/Surface Mount/Suspended |
Length: |
5 Foot |
Package Dimensions: |
1520*84*72mm |
Rated Power: |
44w |
Luminous Efficacy: |
120-150lm/W |
CCT: |
Changeable |
Input Power Supply(v): |
AC 220 |
Warranty: |
5 Years |
Working Temperature: |
-20 - 40(℃) |
Housing Material: |
Stainless Steel |
Install: |
Linkable/Surface Mount/Suspended |
Length: |
5 Foot |
Package Dimensions: |
1520*84*72mm |
5 Foot CCT Changeable LED Wraparound Light Fixture With Stainless Steel Housing
5-foot CCT changeable LED wraparound light fixture features a durable stainless steel housing and high-quality polycarbonate diffuser, designed to provide excellent light diffusion and a sleek, modern appearance. With the flexibility to adjust the color temperature (CCT) from 3000K to 6000K, this fixture allows users to customize the lighting environment to suit various needs. Its energy-efficient SMD2835 LED chips ensure high luminous efficacy, while the IP65 protection rating ensures reliable performance in demanding environments. Ideal for use in parking lots, tunnels, warehouses, and other commercial spaces, this fixture combines both functionality and style.
Durable Stainless Steel Housing: Offers long-lasting protection against wear and environmental stress.
CCT Changeable: Adjustable color temperature (3000K/4000K/5000K/6000K) for customizable lighting.
High Luminous Efficacy: Provides up to 140lm/w, ensuring energy efficiency and bright illumination.
IP65 Protection Rating: Fully sealed design, ideal for use in harsh, wet, and dusty environments.
Microwave Sensor Dimming Option: Available for automatic light adjustment based on movement, saving energy.
| Model | Input voltage | Watt | Sensor Dimming standby | Emergency |
| ZL-VSBLP18-2FT-CN-V2 | AC200-240V | 18w | x | x |
| ZL-VSBLP36-4FT-CN-V2 | AC200-240V | 36w | x | x |
| ZL-VSBLP44-5FT-CN-V2 | AC200-240V | 44w | x | x |
| ZL-VSBLP18-2FT-CS-V2 | AC200-240V | 18w | 100% / 20% /OFF | x |
| ZL-VSBLP36-4FT-CS-V2 | AC200-240V | 36w | 100% / 20% /OFF | x |
| ZL-VSBLP44-5FT-CS-V2 | AC200-240V | 44w | 100% / 20% /OFF | x |
| ZL-VSBLP18-2FT-CE-V2 | AC200-240V | 18w | x | >3hrs@3.6W |
| ZL-VSBLP36-4FT-CE-V2 | AC200-240V | 36w | x | >3hrs@3.6W |
| ZL-VSBLP44-5FT-CE-V2 | AC200-240V | 44w | x | >3hrs@3.6W |
| ZL-VSBLP18-2FT-CES-V2 | AC200-240V | 18w | 100% / 20% /OFF | >3hrs@3.6W |
| ZL-VSBLP36-4FT-CES-V2 | AC200-240V | 36w | 100% / 20% /OFF | >3hrs@3.6W |
| ZL-VSBLP44-5FT-CES-V2 | AC200-240V | 44w | 100% / 20% /OFF | >3hrs@3.6W |
| ZL-VSBLP18-2FT-CN-V1 | AC100-277V | 18w | x | x |
| ZL-VSBLP36-4FT-CN-V1 | AC100-277V | 36w | x | x |
| ZL-VSBLP44-5FT-CN-V1 | AC100-277V | 44w | x | x |
| ZL-VSBLP18-2FT-CS-V1 | AC100-277V | 18w | 100% / 20% /OFF | x |
| ZL-VSBLP36-4FT-CS-V1 | AC100-277V | 36w | 100% / 20% /OFF | x |
| ZL-VSBLP44-5FT-CS-V1 | AC100-277V | 44w | 100% / 20% /OFF | x |
| ZL-VSBLP18-2FT-CE-V1 | AC100-277V | 18w | x | >90mins@7-15W |
| ZL-VSBLP36-4FT-CE-V1 | AC100-277V | 36w | x | >90mins@7-15W |
| ZL-VSBLP44-5FT-CE-V1 | AC100-277V | 44w | x | >90mins@7-15W |
| ZL-VSBLP18-2FT-CES-V1 | AC100-277V | 18w | 100% / 20% /OFF | >90mins@7-15W |
| ZL-VSBLP36-4FT-CES-V1 | AC100-277V | 36w | 100% / 20% /OFF | >90mins@7-15W |
| ZL-VSBLP44-5FT-CES-V1 | AC100-277V | 44w | 100% / 20% /OFF | >90mins@7-15W |
| Note: x -No this function | ||||
| LUMINAIRE INFORMATION | |||
| Model | ZL-VSBLP18-2FT-XX | ZL-VSBLP36-4FT-XX | ZL-VSBLP44-5FT-XX |
| Rated Power | 18W | 36W | 44W |
| Install | Surface Mount/Suspended/Linkable | ||
| Protection Rating | IP4X | ||
| Housing | Steel+AL | ||
| Optics | Polycarbonate Milky Diffuser | ||
| Connection Type | Terminal Block or Linkable | ||
| Operating Temperature | -20℃ to 40℃(Emergency version: 0℃ to 40℃) | ||
| Dimming (Option) | Microwave Sensor - 3 Stepped Version(100%-20%-OFF) | ||
| Emergency (Option) | 3 Hours+ @3.6W or 90Mins+@7--15W LiFePO4 Battery | ||
| PHOTOMETRIC | |||
| Luminous Efficacy | 120-150lm/w | ||
| LED | SMD2835 | ||
| CCT | 3000K/4000K/5000K/6000K | ||
| CRI | 85 | ||
| Beam Angle | 120 degree | ||
| ELECTRICAL | |||
| Input power Supply | AC200-240V, 50/60Hz / AC100-277V, 50/60Hz | ||
| Power Factor | > 0.9 | ||
| Useful Life@Ta25°(L70) | 54,000 hours | ||
| Electrical Classification | Class I | ||
| Dimensions | 620*84*72mm | 1220*84*72mm | 1520*84*72mm |
|
Supermarket |
Metro station |
Corridor |
