Product Details
Place of Origin: Shenzhen, China
Brand Name: COMLED
Certification: FCC,ETL,CE,SAA,AS2293.3,Rosh
Model Number: ZL-CASCLP30-XX/ZL-CBSCLP30-XX
Payment & Shipping Terms
Minimum Order Quantity: 300pcs
Price: EXW US$ 25.9/piece - US$ 41.4/piece
Delivery Time: 7-30 days(sample around 3-7 days)
Payment Terms: T/T
Supply Ability: 8000pcs per month
Rated Power: |
18W / 30W |
Protection Rating: |
IP65 |
CCT: |
3000K/4000K/5000K/6000K |
Warranty: |
3 Years(battery For 1 Year) |
Useful Life@Ta25°(L70): |
54,000 Hours |
Dimensions: |
Ф300*88/Ф300*100 |
Dimming (Option): |
Microwave Sensor - 3 Stepped Version(100%-20%-OFF) |
Emergency (Option): |
3 Hours+ @3W Or 90mins+ @ 7--15W LiFePO4 Battery |
Rated Power: |
18W / 30W |
Protection Rating: |
IP65 |
CCT: |
3000K/4000K/5000K/6000K |
Warranty: |
3 Years(battery For 1 Year) |
Useful Life@Ta25°(L70): |
54,000 Hours |
Dimensions: |
Ф300*88/Ф300*100 |
Dimming (Option): |
Microwave Sensor - 3 Stepped Version(100%-20%-OFF) |
Emergency (Option): |
3 Hours+ @3W Or 90mins+ @ 7--15W LiFePO4 Battery |
IP65 LED Oyster Light 12 In. Selectable CCT White Finish With ON / OFF Microwave Sensor
The IP65 LED Oyster Light is a modern lighting fixture that’s energy efficient. This 12-inch light has a selectable color temperature (CCT) from 3000K to 6500K so you can adjust the light output to fit your environment and task. The white finish is clean and contemporary so it’s perfect for residential and commercial use. Plus it has an ON/OFF microwave sensor so it will turn on and off automatically based on motion detection.
With an IP65 rating, this LED Oyster Light is tough enough to withstand rough conditions, indoor and outdoor. It’s dust and water resistant so it’s perfect for areas like kitchens, bathrooms, hallways and garages. Whether you’re using it in commercial or residential, the Oyster Light gives you optimal light with minimal maintenance.
The selectable CCT lets you choose the right light for your space. Need warm ambiance for living areas or cooler, brighter light for workspaces? This light has you covered. The microwave sensor saves energy and extends the life of the bulb by not using it when the space is unoccupied.
This light is perfect for many applications. Whether you’re fitting out a new project, upgrading an existing lighting system or buying in bulk for distribution, the IP65 LED Oyster Light gives you functionality and style. It’s ideal for engineering contractors, electrical service providers and wholesalers looking for reliable, energy efficient lighting.
◆ Robust Steel housing with IP65 IK10 rate design.
◆ Anti-Glare diffuser design with high transmittance (90%)(Milky option).
◆ High Brightness SMD2835 LED chip as light source (approval by LM80).
◆ Divided patented structural design,easy for on site installation
◆ Split type power supply design, easy maintenance without switch power off on site.
◆ Conpitable with various terminal block for different application wiring.
◆ DIP switch available for changing wattage for different application.
◆ 0-10V or PWM dimming function available (option).
◆ 5.8G HF Sensor dimming function (option).
◆ Emergency available with self-test and self-check (option).
◆ Clip-fixed backup battery for easy maintenance.
◆ Approved by FCC,ETL,CE,SAA,AS2293.3,Rosh.
|
Smart Led Oyster Light Plug& play power supply design for easy maintenance on site |
Smart Led Oyster Light Quick terminal block for easy wiring |
|
Smart Led Oyster Light DIP switch available for changing wattage and CCT for different applications |
Smart Led Oyster Light Emergency available with self-test and self-check (option) |
| Model | Input voltage | Watt | Sensor Dimming standby | Emergency |
| ZL-CASCLP30-CN-V2 | AC200-240V | 18W/30W | x | x |
| ZL-CBSCLP30-CN-V2 | AC200-240V | 18W/30W | x | x |
| ZL-CASCLP30-CS-V2 | AC200-240V | 18W/30W | 100% / 20% /OFF | x |
| ZL-CBSCLP30-CS-V2 | AC200-240V | 18W/30W | 100% / 20% /OFF | x |
| ZL-CASCLP30-CE-V2 | AC200-240V | 18W/30W | x | >3hrs@3W |
| ZL-CBSCLP30-CE-V2 | AC200-240V | 18W/30W | x | >3hrs@3W |
| ZL-CASCLP30-CES-V2 | AC200-240V | 18W/30W | 100% / 20% /OFF | >3hrs@3W |
| ZL-CBSCLP30-CES-V2 | AC200-240V | 18W/30W | 100% / 20% /OFF | >3hrs@3W |
| ZL-CASCLP30-CN-V1 | AC100-277V | 18W/30W | x | x |
| ZL-CBSCLP30-CN-V1 | AC100-277V | 18W/30W | x | x |
| ZL-CASCLP30-CS-V1 | AC100-277V | 18W/30W | 100% / 20% /OFF | x |
| ZL-CBSCLP30-CS-V1 | AC100-277V | 18W/30W | 100% / 20% /OFF | x |
| ZL-CASCLP30-CE-V1 | AC100-277V | 18W/30W | x | >90min@7-15W |
| ZL-CBSCLP30-CE-V1 | AC100-277V | 18W/30W | x | >90min@7-15W |
| ZL-CASCLP30-CES-V1 | AC100-277V | 18W/30W | 100% / 20% /OFF | >90min@7-15W |
| ZL-CBSCLP30-CES-V1 | AC100-277V | 18W/30W | 100% / 20% /OFF | >90min@7-15W |
| Note: x -No this function | ||||
| LUMINAIRE INFORMATION | ||
| Model | ZL-CASCLP30-XX | ZL-CBSCLP30-XX |
| Rated Power | 18W / 30W | 18W / 30W |
| Install | Surface Mount | |
| Protection Rating | IP65 | |
| Housing | Steel with Coating | |
| Optics | Polycarbonate Diffuser | |
| Connection Type | Terminal Block | |
| Operating Temperature | -20℃ to 40℃(Emergency version: 0℃ to 40℃) | |
| Warranty | 3 Years(battery for 1 year) | |
| Half-power Function | 18W or 30W can be set by DIP switch | |
| Dimming (Option) | Microwave Sensor - 3 Stepped Version(100%-20%-OFF) | |
| Emergency (Option) | 3 hours+ @3W or 90mins+ @ 7--15W LiFePO4 Battery | |
| PHOTOMETRIC | ||
| Luminous Efficacy | 118-140lm/w | |
| LED | SMD2835 | |
| CCT | 3000K/4000K/5000K/6000K | |
| CRI | 85 | |
| Beam Angle | 120 degree | |
| ELECTRICAL | ||
| Input power Supply | AC200-240V, 50/60Hz or AC100-277V, 50/60Hz | |
| Power Factor | > 0.9 | |
| Useful Life@Ta25°(L70) | 54,000 hours | |
| Electrical Classification | Class I | |
| Dimensions | Ф300*88 | Ф300*100 |
Widely used in indoor restaurants, bathrooms, corridors, balconies, stairwells, supermarkets, shopping malls and so on.
|
Stair Well |
Corridor |
Tunnel |
